聚(9,9-双(3'-(N,N-二甲基)-N-乙基铵-丙基-2,7-芴)-alt-2,7-(9,9-二辛基芴))二溴化物,PFN-Br; Mw 30,000-50,000 by GPC

别名:聚(9,9-双(3'-(N,N-二甲基)-N-乙基铵-丙基-2,7-芴)-alt-2,7-(9,9-二辛基芴))二溴化物;Poly(9,9-bis(3’-(N,N-dimethyl)-N-ethylammoinium-propyl-2,7-fluorene)-alt-2,7-(9,9-dioctylfluorene))dibromide, OS0995, PFN-P2 线性分子式: (C56H80N2.Br2)n CAS号: 889672-99-5
制造商品牌: 西格玛 Sigma-Aldrich
货号(SKU): 906980
CAS号: 889672-99-5
增值税发票 √ 免费送货 √ 订货电话:010-68689484
¥2,663.20

说明

PFN-Br 是一种可溶液加工的共轭聚合物电解质,用作高性能有机光伏电池 (OPV) 和有机发光二极管 (OLED) 的界面层,以改善界面性能。

具有 PFN-Br 界面层的 OPV 器件在倒置 OPV 中表现出整体增强的短路电流密度、开路电压、填充因子和相应的高效率。 这归因于 ZnO 电子提取层和有源层之间的良好接触,电子提取层和有源层之间良好的界面粘附,以及通过抑制双分子复合增强电荷传输。

应用

PFN-Br is a solution processible, conjugated polymer electrolyte used as interficial layer in high performance organic photovoltaic cells (OPV) and organic light emitting diodes (OLED) to improve the interfacial properties.

OPV devices with PFN-Br interfacial layer showed overall enhanced short-circuit current density, open-circuit voltage, fill factor and corresponding high efficiency in the inverted OPVs. This was attributed to the good contact between ZnO electron extraction layer and the active layer, good interface adhesion between the electron extraction layer and active layer, and enhanced charge transport via suppressed bimolecular recombination.

Recent report of OPV with a record energy conversion efficiency of 17.3% also utilized PFN-Br, spin-coated on top of ZnO to improve the interfacial properties.

Tandem Cell Device performance:
ITO/ZnO/PFN-Br/PBDB-T:F-M/M-PEDOT/ZnO/PTB7- Th:O6T-4F:PC71BM/MoO3/Ag
Voc=1.642 V
Jsc=14.35 mA/cm2
FF=73.7%
PCE=17.3%

PFN-Br finds application in a wide range of areas:
  • OPV interficial layer (metalic oxide compact layer)
  • OLED electron transport layer
  • Perovskite solar cells
  • Flexible printed electronics
  • Cationic polymer electrolyte
  • Anion exchange material
  • Light emitting electrochemical cells

其他说明

Recommend to use 0.2 mg/ml concentration for electron-transport interfacial layer in OPV.



属性

形式

solid

分子量

Mw 30,000-50,000 by GPC

颜色

beige to yellow

溶解性

DMF: soluble
DMSO: soluble
alcohol: soluble
chloroform: insoluble
water: soluble

PDI

2‑3.2



安全信息

储存分类代码

13 - Non Combustible Solids

WGK

WGK 3

商品规格
属性名称属性值
储存温度 Storage temp.常温阴凉避光
全球实时库存 Availability √美国St. Louis ≥ 33 | 欧洲Eur. ≥ 27 | 東京Tokyo ≥ 9 | 香港与北京 ≥ 16
