PBDB-T-2Cl，PM7

图片 PBDB-T-2Cl，PM7
别名：OS0139, PM 7, PCE 139, Poly[[4,8-bis[5-(2-ethylhexyl)-4-chloro-2-thienyl]benzo[1,2-b:4,5-b′]dithiophene-2,6-diyl]-2,5-thiophenediyl[5,7-bis(2-ethylhexyl)-4,8-dioxo-4H,8H-benzo[1,2-c:4,5-c′]dithiophene-1,3-diyl]-2,5-thiophenediyl]

线性分子式: (C68H76C12O2S8)n CAS号: 2239295-71-5
制造商品牌: 西格玛 Sigma-Aldrich
货号（SKU）: 906352
CAS号: 2239295-71-5
签订合同 √ 正规发票 √ 技术支持 √ 质量保障 √ 全程可追溯 √
¥5,216.94

说明

应用

High-Efficiency Organic Solar Cells (OPVs)
Polymeric donor material
LUMO=−3.57 eV
HOMO=−5.32 eV

OPV Device Performance :
PBDB-T-2Cl:IT-4F
Voc= 0.86V
Jsc= 21.46 mA/cm2
FF= 0.75
PCE=13.9%

PBDB-T-2Cl (or PM7) is a wide bandgap polymer donor (n-type semiconductor) containing chlorinated thienyl benzodithiophene (BDT-2Cl) used in high performance polymer solar cells (PSCs). PBDB-T-2Cl-based devices exhibit higher open circuit voltage (Voc) than the PBDB-T-2F-based devices, due to lower molecular energy levels of PBDB-T-2Cl, and leading to an outstanding power conversion efficiency of over 14%.
In general, chlorination is more effective than fluorination in downshifting the molecular energy levels and broadening the absorption spectra.



属性

描述

Band gap: 1.95 eV
Solubility:Soluble in 1,2-Dichlorobenzene

形式

particles

分子量

50,000-100,000 g/mol by GPC

颜色

Fine

溶解性

chlorobenzene: soluble
chloroform: soluble

轨道能量

HOMO -5.52 eV
LUMO -3.57 eV

PDI

2‑4



安全信息

储存分类代码

11 - Combustible Solids

WGK

WGK 3

商品规格
属性名称属性值
储存温度 Storage temp.常温阴凉避光
全球实时库存 Availability √美国St. Louis ≥ 50 | 欧洲Eur. ≥ 12 | 東京Tokyo ≥ 20 | 香港与北京 ≥ 50
