2,2',7,7'-四(N,N-二-对甲苯基)氨基-9,9-螺二芴,Spiro-TTB;≥99% (HPLC)

别名:2,2′,7,7′- Tetrakis(N,N′-di-p-methylphenylamino)-9,9′-spirobifluorene, 2,2′,7,7′-Tetra(N,N-di-p-tolyl)amino-9,9-spirobifluorene, 2,2′,7,7′-Tetrakis(di-p-tolylamino)spiro-9,9′-bifluorene, 2,2′,7,7′-Tetra(N,N-ditolylL)amino-9,9-spiro-bifluorene, 2,2′,7,7′-Tetra(N, N-di-tolyl)amino-spiro-bifluorene, N2,N2,N2′,N2′,N7,N7,N7′,N7′-Octa-p-tolyl-9,9′-spirobi[fluorene]-2,2′,7,7′-tetraamine, 2,2′,7,7′-Tetrakis(di-p-tolylamino)-9,9′-spirobi[fluorene]

Empirical Formula (Hill Notation): C81H68N4 CAS号: 515834-67-0 分子量: 1097.43 MDL编号: MFCD28968052
制造商品牌: 西格玛 Sigma-Aldrich
货号(SKU): 923192
CAS号: 515834-67-0
MDL号: MFCD28968052
增值税发票 √ 免费送货 √ 订货电话:010-68689484
¥2,657.15

说明

一般描述

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product belongs to enabling category of greener alternatives, and has been enhanced for energy efficiency. Click here for more information.


应用

Spiro-TTB is a high-mobility organic semiconductor with strong donor character given its four substituted arylamine moieties that stabilize positively charged cationic states via mesomeric effects.
It has been successfully applied as transparent hole-transparent layer in solar cells, organic field-effect transistors (OFETs), and organic light emitting devices (OLEDs). In photovoltaics, spiro-TTB was used as organic hole selective layer between perovskite and the silicon cells, contributing to a 25.2% efficency perovskite/ silicon tandem solar cell. When used in OLEDs, spiro-TTB enabled applications in organic photodetectors (OPDs), imaging and lasing applications.



属性

描述

PL:409 nm (in THF)
TGA:> 360 °C (0.5% weight loss)
Tg: 146 °C

质量水平

100

测定

≥99% (HPLC)

分子量

average mol wt 1097.43 g/mol

环保替代产品特性

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

缺失

0.5% TGA, >360°C

转变温度

Tg 146 °C

溶解性

THF: soluble

λmax

385 nm in THF

轨道能量

HOMO 5.2 eV
LUMO 1.9 eV

环保替代产品分类

Enabling



安全信息

储存分类代码

11 - Combustible Solids

WGK

WGK 3

商品规格
属性名称属性值
储存温度 Storage temp.常温阴凉避光
全球实时库存 Availability √美国St. Louis ≥ 99 | 欧洲Eur. ≥ 10 | 東京Tokyo ≥ 22 | 香港与北京 ≥ 32
