钛酸锂 [尖晶石]，Lithium titanate；spinel, electrode sheet, aluminum substrate, size 5 in. × 10 in.

别名：钛酸锂尖晶石氧化物；尖晶石钛酸锂；LTO纳米粉末；钛酸锂；LTO nanopowder, Lithium titanate spinel oxide, Lithium titanium oxide

线性分子式: Li4Ti5O12 CAS号: 12031-95-7 分子量: 459.09 MDL编号: MFCD11656084 PubChem化学物质编号: 329762360 NACRES: NA.23

制造商品牌: 西格玛 Sigma-Aldrich

货号（SKU）: 765155

CAS号: 12031-95-7

MDL号: MFCD11656084

增值税发票 √ 免费送货 √ 订货电话：010-68689484

目录价.SKU-Variant

100g

¥7,667.87

数量:

说明

钛酸锂 (LTO) 是一类可用于制造锂离子电池的电极材料。锂离子电池由阳极、阴极和电解液组成，具有充放电循环。这些材料能够形成用于电能存储的更环保和可持续的电池。
我们致力于为您带来更环保的替代产品，这些产品符合绿色化学 12 项原则中的一项或多项。该产品已提高能源效率。在此处查找详细信息。
钛酸锂 (LTO) 尖晶石电极片可用作阳极材料，其在室温下的离子电导率为 10-3 Scm-1。它也可以用作传统石墨材料的替代品。它还可以进一步用于制造用于电动汽车 (EV) 的高性能锂离子电池。

一般描述

Lithium titanate (LTO) is a class of electrode material that can be used in the fabrication of lithium-ion batteries. Lithium-ion batteries consist of anode, cathode, and electrolyte with a charge-discharge cycle. These materials enable the formation of greener and sustainable batteries for electrical energy storage.

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Find details here.

应用

Lithium titanate (LTO) spinel electrode sheet can be used as an anode material, which shows an ion conductivity of 10⁻³ Scm⁻¹ at room temperature. It can also be used as an alternative to conventional graphite materials. It can further be used in the fabrication of high-performance lithium-ion batteries for electric vehicles (EVs).

其他说明

Crystal Structure: Spinel, cubic, Fd-3m

Operating Condiditons:

Recommended maximum charge voltage: 3.0 V vs Li/Li⁺
Recommended maximum charge current: 5 C
Recommended cut-off voltage for discharge: 1.0 V vs Li/Li⁺
Recommended maximum discharge current: 10 C

属性

描述

Nominal Voltage: 1.5 V, Li/Li+

质量水平

100

测定

≥98%

形式

sheet

环保替代产品特性

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

标记范围

≥80% loading

尺寸

5 in. × 10 in.

厚度

25-50 μm

容量

150 mAh/g(minimum)
160 mAh/g(nominal at 0.1C)

mp

>1000 °C

application(s)

battery manufacturing

环保替代产品分类

Enabling

SMILES string

[Li+].[Li+].[Li+].[Li+].[O-][Ti](=O)O[Ti](O[Ti]([O-])=O)(O[Ti]([O-])=O)O[Ti]([O-])=O

InChI

1S/4Li.12O.5Ti/q4*+1;;;;;;;;;4*-1;;;;;

InChI key

BNQVSKURWGZJMY-UHFFFAOYSA-N

安全信息

储存分类代码

11 - Combustible Solids

WGK

WGK 3

商品规格

属性名称	属性值
储存温度 Storage temp.	常温阴凉避光
全球实时库存 Availability √	美国St. Louis ≥ 55 \| 欧洲Eur. ≥ 16 \| 東京Tokyo ≥ 8 \| 香港与北京 ≥ 10
