高取代苯基疏水相互作用层析树脂,Capto Phenyl (High Sub) hydrophobic interaction chromatography resin

Capto Phenyl (High Sub) 树脂适用于蛋白质纯化的中间阶段,结合了高容量、高流速和低背压,可缩短工艺循环时间。17545105;17545101;17545103;17545104;17545102
货号(SKU): 17545103
增值税发票 √ 免费送货 √ 订货电话:010-68689484

Useful for the intermediate stages of protein purification, Capto Phenyl (High Sub) resin combines high capacity, high flow rate, and low back pressure to reduce process cycle times.

Capto Phenyl (High Sub) 树脂有以下几种形式:

PreDictor Capto Phenyl (High Sub) 过滤板、用于高通量筛选或工艺开发的 96 孔板。
PreDictor Capto Phenyl (High Sub) RoboColumn™ 装置,用于高通量工艺开发的微型柱。
HiScreen Capto Phenyl (High Sub) 色谱柱,针对方法和工艺开发进行了优化。


Prepacked columns and other formats

Capto Phenyl (High Sub) resin is available in the following formats:

Process development scale: prepacked

  • PreDictor Capto Phenyl (High Sub) filter plates, 96-well plates for high-throughput screening or process development.
  • PreDictor Capto Phenyl (High Sub) RoboColumn™ units, miniaturized columns for high-throughput process development.
  • HiScreen Capto Phenyl (High Sub) columns, optimized for method and process development.

Lab scale: prepacked for manual purification

HiTrap Capto Phenyl (High Sub) columns, for easy use with a syringe, peristaltic pump, or chromatography system.

Lab scale: prepacked for automated purification and analysis

HiTrap Capto Phenyl (High Sub) columns, for easy use with a syringe, peristaltic pump, or chromatography system.

Process characterization: resin kits

Process Characterization Kit Capto Phenyl (high sub), designed for studying the potential impact that resin ligand density might have on the process outcome.

Process-scale purification: prepacked

ReadyToProcess Capto Phenyl (high sub) columns, 1 L and larger columns for clinical manufacturing that minimize the need for cleaning and cleaning validation.


ParameterCapto Phenyl (High Sub), 1 L
Chromatography techniqueHydrophobic Interaction Chromatography
BioProcess resinYes
Particle size, d50V1~75 µm
MatrixHighly cross-linked agarose
Ligand Coupling MethodEther linkages and hydrophilic spacer arm
Binding Capacity/ml Chromatography Medium27 mg BSA /mL (at QB10 %)
Ligand densityApprox. 27 μmol/ml drained medium
pH stability, operational23–13
pH stability, CIP32–14
Pressure/Flow Specification300 kPa at 600 cm/h, 1 m diameter column, 20 cm bed height
Coupling ChemistryEpoxy
Storage4 to 30°C, 20% Ethanol
Chemical stabilityStable to commonly used aqueous buffers
Pack size1 L
  • 1Median particle size of the cumulative volume distribution.
  • 2pH range where resin can be operated without significant change in function.
  • 3pH range where resin can be subjected to cleaning- or sanitization-in-place without significant change in function.
储存温度 Storage temp.常温阴凉避光
全球实时库存 Availability √美国St. Louis ≥ 33 | 欧洲Eur. ≥ 27 | 東京Tokyo ≥ 9 | 香港与北京 ≥ 16
