氯化硼亚酞菁，Boron subphthalocyanine chloride；Dye content ~85 %

形式

solid

质量水平

100

组成

Dye content, ~85%

mp

>360 °C (lit.)

λ_max

565 nm

OPV设备性能

ITO/MoO3/SubPc/F16CuPc/BCP/Al

• Short-circuit current density (J_sc): 2.54 mA/cm²
• Open-circuit voltage (V_oc): 0.4 V
• Fill Factor (FF): 0.55
• Power Conversion Efficiency (PCE): 0.56 %

ITO/SubPc/F16CuPc/Al

• Short-circuit current density (J_sc): 0.46 mA/cm²
• Open-circuit voltage (V_oc): 0.22 V
• Fill Factor (FF): 0.21
• Power Conversion Efficiency (PCE): 0.02 %

ITO/SubPc/F16CuPc/BCP/Al

• Short-circuit current density (J_sc): 1.9 mA/cm²
• Open-circuit voltage (V_oc): 0.21 V
• Fill Factor (FF): 0.31
• Power Conversion Efficiency (PCE): 0.13 %

SMILES string

Clb1n2c3nc4nc(nc5c6ccccc6c(nc2c7ccccc37)n15)c8ccccc48

InChI

1S/C24H12BClN6/c26-25-31-21-15-9-3-5-11-17(15)23(31)30-24-18-12-6-4-10-16(18)22(32(24)25)29-20-14-8-2-1-7-13(14)19(27-20)28-21/h1-12H/b28-19-,28-21-,29-20-,29-22-

InChI key

IFJKCEPOUBWFFD-QJAIGJGMSA-N

象形图

GHS07

警示用语：

Warning

危险声明

H315 - H319 - H335

预防措施声明

P261 - P264 - P271 - P280 - P302 + P352 - P305 + P351 + P338

危险分类

Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

靶器官

Respiratory system

储存分类代码

11 - Combustible Solids

WGK

WGK 3
